“Tag, You‘re It!” Tagging proteins with ubiquitin by different E3 ligases may be key to specificity of the ubiquitin-dependent protein degradation

In 2011, a collaboration between Hiroaki Kiyokawa, NU and Jun Yin, currently at Georgia State University but formerly at UChicago, led to a CBC Catalyst Award to “Identify Cell Cycle-Regulatory Substrates Ubiquitinated by the Apoptosis Inhibitor BRUCE.” In 2014, Kiyokawa and his postdoc, Xianpeng Liu, applied and received a CBC Postdoctoral Research Award to “Identify ubiquitination substrates specific for the non-canonical E1 enzyme UBA6.” Two recent publications in Nature Communications and in Science Advances resulted from the CBC funding. Yin and Kiyokawa are senior co-authors, and Liu a co-author on both publications. The papers describe a clever technology to study the role of distinct E3 ligases in the specificity of ubiquitin-dependent protein degradation, a process implicated in the pathology of many human diseases including cancer and autism. Congratulations to both teams!

Tracking Protein Disposal Could Lead to Improved Therapies

Northwestern Medicine News Center   |   by Will Doss   |   January 9, 2018

Hiroaki Kiyokawa, MD, PhD

Hiroaki Kiyokawa, MD, PhD, professor of Pharmacology and of Pathology, was co-senior author on studies published in Nature Communications and Science Advances.

Northwestern Medicine investigators developed a technique to catalog how cells dispose of unnecessary proteins, a process that has implications for cancer and autism-spectrum diseases, according to findings published in Nature Communications.

Defects in ubiquitination, or how cells dispose of unneeded proteins, have been implicated in a variety of diseases, but scientists have previously lacked a reliable method for tracking the enzymes involved in this disposal process, according to Hiroaki Kiyokawa, MD, PhD, professor of Pharmacology and co-senior author on the study.

To combat this, a collaborative team led by Kiyokawa and Jun Yin, PhD, associate professor of Chemistry at Georgia State University, developed orthogonal ubiquitin transfer, a method of tracking which enzymes trigger disposal of which proteins. This technique may give scientists a better understanding of the mechanisms of disease arising from abnormal ubiquitination, hopefully leading to improved therapy, Kiyokawa said.

Ubiquitination flags proteins for destruction and is facilitated by three classes of enzymes; E1, E2 and E3 enzymes. Ubiquitin is bound to the three enzymes in sequence, but E1 and E2 enzymes are simple primer enzymes, so mammalian cells have just a limited number of E1 and E2 varieties. On the other hand, there are hundreds of E3 enzymes, suggesting each E3 has its own unique protein target.

“The relationship between E3 enzymes and the target protein is like a lock and a key,” said Kiyokawa, also a professor of Pathology and a member of the Robert. H. Lurie Comprehensive Cancer Center of Northwestern University.

The diversity of target proteins and weak interactions mean it can be challenging to clearly identify which E3 enzyme tags which protein. However, orthogonal ubiquitin transfer (OUT) is a novel solution to the problem, according to Kiyokawa.

In OUT, scientists engineered an artificial ubiquitin pathway that mimics the native system but only responds to mutated ubiquitin, which has a special tag that allows scientists to identify the protein it eventually targets at the end of the cycle.

Illustration showing ubiquitin moving from an E1 enzyme to an E2 enzyme.

“There are two pathways within the same cells,” Kiyokawa said. “The original is like a highway, and the engineered pathway is a detour.”

In the current study, the investigators constructed an artificial pathway for an E3 enzyme called E6AP, and introduced the mutated ubiquitin and pathways into cells. After a proteomics screen, the scientists were able to identify the specific protein targets of E6AP.

“This study is just a showcase of the technology, but we believe we can apply this to many of the 600 E3 proteins without too much hassle,” Kiyokawa said. “Quite a few E3 enzymes are known to be overexpressed or mutated in neuronal diseases, so there’s a large pool of research opportunities.”

However, E6AP in particular has been shown to target tumor suppressor proteins when improperly activated by the human papillomavirus, contributing to the increased cancer risk faced by infected patients. In addition, the gene locus that codes for E6AP is known to be mutated in Angelman syndrome, an autism-spectrum disorder.

“We still don’t know why E6AP needs to be mutated to show symptoms of Angelman syndrome, but investigation into specific targets may teach us more about the pathophysiological mechanisms of autistic disease,” Kiyokawa said.

Further investigation into specific targets is already underway — Kiyokawa and colleagues recently published another study involving OUT, this time in Science Advances.

They found a different E3 enzyme, CHIP, was involved in degradation of CDK4, an enzyme that plays a key role in cell proliferation.

“It seems to be a mechanism that can stop the cell cycle under stress,” Kiyokawa said. “If this regulation is broken, the organism may be more susceptible to cancer.”

Yet, it’s not enough to simply identify these targets of ubiquitination, according to Kiyokawa.

“We need to learn why these newly defined targets are under the regulation of E3 enzymes if we wish to find new therapeutic targets,” he said. “Only then can we develop drugs or treatments.”

The Nature Communications study was supported by National Institutes of Health (NIH) grants GM104498 and CA112282, the National Science Foundation (NSF) grants 1420193 and 1710460, the Chicago Biomedical Consortium grants Catalyst-026 and PDR-010, Project 985 startup grants WF220417001 and WF114117001, the Lynn Sage Breast Cancer Research Foundation and the Department of Pharmacology at Northwestern University.

The Science Advances study was supported by NIH grants GM104498, CA112282, GM075156 and GM118089, NSF grants 1420193 and 1710460, the Chicago Biomedical Consortium grants Catalyst-026 and PDR-010, and the National Natural Science Foundation of China grant 31770921 and by Project 985 start-up grants WF220417001 and WF114117001/004, the Lynn Sage Breast Cancer Research Foundation and the fund from the Department of Pharmacology at Northwestern University. This study was supported in part by the EIPC, which is subsidized by the Emory University School of Medicine.


Adapted (with modifications) from Northwestern Medicine News Center, by Will Doss, posted on January 9, 2018.


Wang Y, Liu X, Zhou L, Duong D, Bhuripanyo K, Zhao B, Zhou H, Liu R, Bi Y, Kiyokawa H, Yin J. Identifying the ubiquitination targets of E6AP by orthogonal ubiquitin transfer. Nat Commun. 2017 Dec 20;8(1):2232. (PubMed)

Bhuripanyo K, Yiyang Wang Y, Liu X, Zhou L, Liu R, Duong D, Zhao B, Bi Y, Zhou H, Chen G, Seyfried NT, Chazin WJ, Kiyokawa H, Yin J. Identifying the substrate proteins of U-box E3s E4B and CHIP by orthogonal ubiquitin transfer. Science Advances. 2018 Jan 3;Vol. 4, no. 1, e1701393. [Epub ahead of print] (
